DN100 PN16 Stainless Steel Wafer Butterfly Valve Body with 1.4408 Gland | CF8M Manufacturer
CF8M/EN 1.4408 stainless steel cast DN100 PN16 wafer butterfly valve body with matched 1.4408 gland. Good corrosion resistance for water, steam, marine and mild chemical service. CNC machined sealing and stem areas. Support custom lug/wafer pattern, seat material, actuator mount, dimensions and cast marks for OEM valve projects.
Material:
1.4308/1.4408/1.4469/1.4470/1.4588/C276 and more
Dimension:
DN25 – DN400
Pressure:
PN3-PN25
Casting:
Investment Casting
Certificate:
PED
Approval by Lloyd's Register Classification of China
Descriptions
Parametric
Specificities
Details
Case
DN100 PN16 Wafer Butterfly Valve Body Assembly
CF8M / 1.4408 Cast Stainless — Mo-bearing austenitic stainless, excellent resistance to water, steam, mild acids and chloride pitting.
Gland in matched 1.4408 — Same alloy family as body/bonnet, no galvanic corrosion between stem packing house and body.
PN16 / DN100 Wafer Body — Compact, corrosion-proof alternative to ductile iron in HVAC, marine and chemical lines.
CNC Seat & Stem Bore — Tight tolerance, low stem friction, reliable packing compression.
Full Traceability — Cast heat no. + EN 10204 3.1 MTR available.
OEM Ready — Lug/wafer, lever/gear/actuator, seat elastomer all customizable.
Get In Touch With Us
Gland in matched 1.4408 — Same alloy family as body/bonnet, no galvanic corrosion between stem packing house and body.
PN16 / DN100 Wafer Body — Compact, corrosion-proof alternative to ductile iron in HVAC, marine and chemical lines.
CNC Seat & Stem Bore — Tight tolerance, low stem friction, reliable packing compression.
Full Traceability — Cast heat no. + EN 10204 3.1 MTR available.
OEM Ready — Lug/wafer, lever/gear/actuator, seat elastomer all customizable.
20
+
Year/Experiences
245
+
Employees
Product Parameters
| Manufacture Process: | Investment casting |
| Heat Treatment: | Solution annealing |
| Maximum Part Size: | 500mm |
| Minimum part size: | 25mm |
| Certificate: | PED |
| Material Standard: | EN10213/EN10088-1/ASTM A351/A351M and more |
Product Features
Customer customization
We can develop patterns and produce corresponding products according to customer requirements.
Product accuracy
Machining is carried out through CNC lathes and machining centers to ensure good product accuracy.
Casting dimensions
Investment casting ensures good dimensional accuracy and surface finish of the castings.
Stability
With a monthly production capacity of over 80,000 valve disks, we guarantee product quality and timely delivery.
Professionalism
Having been engaged in the valve field for more than 15 years, we can help customers complete the production of various products.
Certification
Approval by Lloyd's Register Classification of China, our products can be used in the marine industry.
Product Parameters
On The Basis Of Deepening Co-Operation With Existing Customers, We Continue To Develop New Customers In The Market And Provide Customers
Material Composition
Body and gland are produced from EN 1.4408 (GX5CrNiMo19-11-2) cast austenitic stainless steel, equivalent to ASTM A351 CF8M / JIS SCS14A. The Mo-bearing chemistry (2–2.5% Mo) delivers superior resistance to chloride-induced pitting and crevice corrosion compared to standard 18/8 grades. Solution-annealed for optimal ductility and corrosion performance. MTR (EN 10204 3.1) available on request.
1
Dimensional Specifications
DN100 nominal bore, PN16 pressure rating. Standard wafer face-to-face per EN 558 / ISO 5752. Lug hole pattern and top flange drilling to customer specification. Cast identification "6743 DN100" for traceability. Custom wall thickness, seat groove depth, and hole layouts available from drawings.
3
Certifications And Approvals
Material traceability by cast heat number. EN 10204 3.1 MTR supplied on request covering chemical analysis and mechanical properties (Rm 440–640 MPa, Rp0.2 ≥185 MPa). Hydrostatic shell test and seat test per API 598 / EN 12266 available. Third-party inspection supported.
5
Design And Construction
Wafer-type butterfly valve body with dual lug mounting holes and a central elastomeric seat groove. Integrated top flange (ISO 5211 pattern) accepts stem and actuator. Gland (packing gland) in matched 1.4408 compresses graphite or PTFE packing against the stem for zero external leakage. Compact sandwich profile fits between standard PN16 flanges.
2
Surface Finishing
CNC-machined sealing faces and stem bore with controlled surface roughness. Natural mill finish as standard; pickling/passivation or electropolish available for hygienic or aggressive-service applications. Machined gland mating surfaces hold tight tolerances for consistent packing compression.
4
Customization And Modifications
OEM and drawing-based customization welcomed. Options include: seat elastomer (EPDM / NBR / PTFE / Viton), stem material (1.4401 / 17-4PH), surface treatment (passivation / electropolish), actuator mounting (ISO 5211 flange), and lug pattern modification. Prototyping and batch production for DN100 CF8M wafer valve bodies and gland assemblies.
6
